18650 21700 Cylinder Cell Battery Crimping Machine 120w Li Ion Battery Sealing Machine

  • 1
  • 2

Brand Name : Gelon

Model Number : Cylinder Cell Crimping Machine

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : USD$1800~3200 per set

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 1000 sets per month

Delivery Time : 20~25days

Packaging Details : Standard packing/Wood packing

product name : Battery Sealing Machine

Product name : Cylinder cell Crimping Machine

Materials : Heavy Duty Steel Platform ,plating and spraying no rust

Air supply : compressed air 0.6~1.0MPa

Sealing Pressure : 10~150kg/cm2

Power : 120w

Warranty : 1 year

Weight : 35kg

Dimensions : 385mm X 160mm X 325mm

Application : 18650/26650/32650/21700

Contact Now

Battery Equipment18650,21700 Cylindrical Cases Pneumatic Crimper Crimping Equipment Lithium Ion Battery Sealing Machine

The pneumatic crimping machine is driven by a cylinder to realize the packaging process for the cylindrical battery. The standard configuration mold can be used for the sealing of 18650 batteries. After replacing the mold, other cylindrical batteries (such as 26650) can be sealed.

Driving Force Manual hydraulic pressingup to 5T
Pressure Gauge 0-3500 psi (0-250 kg/cm^2)
Body Stainless Steel
Crimping Dies Six standard die selectable: CR123 /18650 / 26650 / 32650 / AA /AAA
Compliance CE certified
Warranty
  • One year limited with lifetime support
  • Parts rusted without regular cleaning and maintenance are not covered
Product Dimensions 320mm(L) x 240mm(W) x 400mm(H)
Application Notes
  • Customized die for other cylindrical cell types is available upon request
  • It is necessary to groove the opening end of the cylindrical case by using the GN-500 grooving machine before sealing the cap
  • Each type of cylinder cell can only be sealed specifically by certain model of equipment.
  • We will also provide free cylindrical cases along with the equipment for your operation practice.
Net Weight 40kg
